| 1000m Reflectorless Range |
 |
8 * 1.5GHz CPU 4+64GB Memory |
|
5.5″ Screen1280 * 720, High Clarity | |
4G + wifi +BT Communication |
       |
More Powerful than Ever, More Versatile than Ever!
KTS-552 Android Total Station is equipped with an 8 -cores 1.5GHz CPU, 4+64 GB memory, the system works much smoother and calculate much faster than old generation equipment, it also performs better when importing large size base map or CAD designing files.
  Video: https://www.youtube.com/watch?v=YgeHbx-Mez0
|
| Simple and Upgradable!
KTS-552 is powered by Android 11 OS, easy to learn, combined with Kolida SurveyStar field software, it offers a simple and productive way of working Moreover, user can develop and install their own application into the system, to meettheir special work demand… Â Â |
      |
       |
Measures Longer and longer, Improvement Never Settles! How could we lift the ranging cabability to a new level of 1000m? The three key factors are “Dual-light Source Distance Measuring technology”, optimization of the signal-to-noise ratio, a more stable objective lens system. Video: 1000m Non-prism measurement in cloudy weather https://www.youtube.com/watch?v=bpnFW2EdxVY
|
| A New Step to be More Accurate,
Innovation Never Stops!
Every hard working surveyor deserves a higher precision than before. Four innovations have been realized in our newly designed optical system to achieve this goal: “Focal Length Compensation Mirror”, “Fully sealed emitting laser circuit”, “Less reflectors in optical part”, “the 4th Generation EDM CPU”. Article:Â http://www.kolidainstrument.com/news/details/id/113.html |
      |
      |
Practical Survey Program
Various of surveying programs onboard allow surveyors to complete their tasks directly in the field: Resection, Point to Line, Free Station, Point Collect, Distance Offset, Plane Offset, Column Offset, REM, Line & Point, Line & Angle, Point Setout, Reference Line, Line Setout, Arc Setout, Reduction, XYZ Calc., Inverse, Area & Girth, Dist. Conversation, Angle Conversation, Average, Triangle Calc., Calculator…
|
| Easy for Training and Learning
Thanks for the Air mirroring function of Android OS, now user can share total station screen to other devices, to make demonstration/ training more intuitive and productive. |
       |
| Distance Measurement | ||
| Measurement Range1 prism:          5000m3 prism:          8000-10000mReflectorless:      1000m | AccuracyPrism:         ±(2+2ppmx D)mmReflectorless:    ±(3+2ppmx D)mm | Measuring Time0.1 – 1.5s |
| Atmosphere CorrectionAuto correction by manually input Parameters | Prism Constant CorrectionAuto correction by manually input Parameters | |
| Â | ||
| Angle Measurement | ||
| Measurement MeAbsolute Encoding |
Accuracy2″ |
Minimum Reading1″/ 5″ optional |
| CompensatorDual Axis Liquid-electricRange ±4′, Accuracy 1″ | ||
| User Interaction | ||
| Operation SystemAndroid 11 OS | Color ScreenYes, 1280 * 720 | Touch ScreenYes |
| KeyboardNumeric keys with backlight | Trigger KeyN/A | Bluetooth & wifiBluetooth, wifi, 4G |
| Internal Storage4 + 64GB | External Storage
USB Type C (OTG) and TF Card |
|
| Working Capability | ||
| ProgramCAD Setout, Coordinate measurement, setout, area, road design… | Graphic Display Yes |
Laser Pointer & Laser PlummetYes |
| Endurance8 hours | Setout Guide Light
N/A |
Camera Function
N/A |
