| Long Battery Life 32 hours Standby Time |
 |
Trigger Key Fast Measurement |
|
Guide LightRapid & Simplified Stakeout | |
T/P Sensor Reliable & Stable Measurement |
| Guide Light Technology,
Rapid and Simplified Stakeout
Empowered by the guide light, the stakeout becomes more efficiently! Whether in dim or complex environments, the KTS-442P allows you to effortlessly complete stakeout work. It enables rapid positioning without the worry of sight-distance limitations. The Green/ Red light will guide the prism-man to move to correct direction
|
 |
 |
T/P Sensor, Reliable & Stable Measurements Sometimes surveyors forget to input temperature/ pressure value, now it is no more a headache. KTS-442P has newly added T/P sensors, which can automatically read temperature and air pressure, then calculate correction parameter. Your measurement results will be more reliable and precise.
|
| Farewell to Frequent Charging!
Efficiency & Precision hand in hand
The KTS-442P is newly equipped with two 5000mAh batteries. Each single battery can stand by for up to 32 hours, enabling you to work continuously and efficiently during long-term measurement tasks. There is no need to replace the batteries frequently，allowing you to focus on every precise measurement moment. |
 |
 |
Measure & Setout on App, More Productive & Smarter! Ksurvey App allows you to import CAD basemap and stakeout it, without input point coordinates one by one. Online map can be displayed with CAD map too. Point Stakeout and Line stakeout now is in graphic display. It brings more ease and convenience to your work.
|
| Map & Draw on Android App,
Save Time Outdoor & Indoor!
|
 |
 |
Measures Longer and longer, Improvement Never Settles! How could we lift the ranging cabability to a new level of 1000/1500m? The three key factors are “Dual-light Source Distance Measuring technology”, optimization of the signal-to-noise ratio, a more stable objective lens system. Video: 1000m and 1500m Non-prism measurement in cloudy weather https://www.youtube.com/watch?v=bpnFW2EdxVY
|
| A New Step to be More Accurate,
Innovation Never Stops!
Every hard working surveyor deserves a higher precision than before. Four innovations have been realized in our newly designed optical system to achieve this goal: “Focal Length Compensation Mirror”, “Fully sealed emitting laser circuit”, “Less reflectors in optical part”, “the 4th Generation EDM CPU”. |
 |
 |
Practical Survey Program
Various of surveying programs onboard allow surveyors to complete their tasks directly in the field: angle offset, angle repetition, dual-distance offset, coordinate measurement, REM, MLM, Staking out,area calculation, Road Design, etc. Video: https://www.linkedin.com/pulse/operation-video-kts-442r6lc-andy-lau/
|
|
Convenient Data Transfer
KTS-442P supports USB and/ or Bluetooth connection. User can use a Pendrive to download data from total station directly, or use Ksurvey App to download and share to office. One time download can export data in four formats: .csv, .xls, .txt, .dxf. |
 |
| Distance Measurement | ||
| Measurement Range1 prism: 5000m3 prism: 8000-10000mReflectorless: 1000/ 1500m | AccuracyPrism & Reflector Sheet: ±(2+2ppmx D)mmReflectorless: ±(3+2ppmx D)mm | Measuring Time0.1 – 0.3s (Prism)0.3 – 3s (non-prism) |
| Atmosphere CorrectionAuto Input, Auto Correction | Prism Constant CorrectionManual Input | |
| Angle Measurement | ||
| Measurement MeAbsolute Encoding |
Accuracy2″ |
Minimum Reading1″/ 5″ optional |
| CompensatorDual Axis Liquid-electricRange ±4′, Accuracy 1″ | ||
| User Interaction | ||
| Operation SystemReal Time | Color ScreenN/A |
Touch ScreenN/A |
| KeyboardFull Alphanumeric keys with backlight | Trigger KeyYes | Bluetooth & wifiBluetooth |
| Internal Storage12Mb, 100,000 points | External Storage
up to 32GB USB Flash Memory |
|
| Working Capability | ||
| ProgramCoordinate measurement, setout, area, road design… | Graphic Display N/A |
Laser Pointer & Laser PlummetYes |
| Endurance32 hours standby time by single battery, totally 2 batteries | Setout Guide Light
Yes, (Red/Green) |
Camera Function
N/A |
| T/P SensorAuto Sensor and set |
